Imperial Range Equipment is made in USAImerial Range Products at Dvorson's
Imperial Home Ranges Please Note: Imperial's Residential Range Models were Retired in 2016 - See Alternates:

American Range
THOR Kitchen Appliances: Professional Ranges and Hoods

Imperial® Commercial Fryers & Ranges | Teppanyaki Griddles

Imperial ranges for the home offered commercial quality, extended depth and even a raised griddle/broiler option.
Our 61" showroom model was a head turner. Professional Residential Models shown below

Please Contact us for replacement parts for all Imperial Residential Ranges (View parts diagram here)
1-877-386-7766

61" Home range with 6 open burners,
24" griddle/broiler are two 26 1/2"
ovens shown with optional glass oven doors

37"
Model shown above: 37" Home range
with optional 22" SS riser & high shelf
and San Franciscan Sourdough!


61" Home range with 6 open burners,
24" griddle/broiler and Two 26.5" ovens

Imperial Residential Home Ranges in 37" , 49" , or 61" widths

Standard Features

  • Electronic Ignition with automatic re-ignition
  • Full Size Oven (14" height x 21" deep x 26 1/2" width) oven with porcelainized interior
  • Built-in gas regulator with 3/4" NPT inlet
  • AGA certified safe for residential use
  • Contemporary styling with commercial grade construction
  • All stainless steel front
  • 11" high stainless steel backguard
  • Removable porcelain cast iron top grates with cast-in bowls
  • Two heavy duty chrome plated adjustable oven racks and removable side supports per oven
  • Easy lift off oven doors
  • 15,000 BTU removable cast iron open burners
  • Gas controls have child proof push-to-turn, cool touch knobs
  • Pilotless electronic ignition for all burners and oven
  • Commercial oven controls and indicator light system
  • Available with open burners, 3/4" thick griddles and raised griddle/broilers


Specifications:

  • Open Burners: Removable porcelainized 12" x 24" cast iron grates. Commercial design heavy duty cast iron burners. 15,000 BTU burner.
  • Griddle: 3/4" thick steel plate 15,000 burner with manual controls every 12".
  • Raised Griddle/Broiler: Available with 3/4" thick steel plate. Removable chrome plated broiler rack. 15,000 BTU burner every 12".
  • Oven: 1 hour manual timer. 30,000 BTU burner. Manual timer not available with 61" model. Full size 26 1/2" oven with porcelainized interior. Two heavy chrome plated, 5 position oven racks and removable side supports for easy cleaning.
  • Gas Inlet: 3/4" NPT gas inlet is located on the opposite side of the griddle. ie. IDR-6RG24 gas inlet is located in rear of range, 8" in from right side rear, 31.5" up from floor.
  • Electrical connection located in rear of range near gas inlet.
    6' grounded plug, 120 volt AC, single phase 1 AMP
  • Clearances: 0" sides and back, 6" bottom
  • Specifications / Data Sheet (all models) »


Optional Accessories:

  • Oven door Window
  • Wok ring
  • Stainless steel griddle cover / work surface
  • Grooved griddle
  • Stainless steel curb base
  • Extra oven rack
  • Hardwood cutting board
  • Casters
  • See all options available »
Imperial Home Range IDR-6-RG24


Imperial Residential Ranges by DvorsonsImperial 37" Home Range with One 26-1/2" Oven
Model
Top Configuration
Gas Output
Ship Wt. lbs.
IDR-6
6 Open Burners
120,000
580
IDR-4-G12
4 Open Burners, 12" Griddle
105,000
585
IDR-2-G12-2
4 Open Burners - 2 left 2 right, 12" Center Griddle
105,000
590
IDR-4-RG12
4 Open Burners, 12" Raised Griddle
105,000
590
IDR-2-RG24
2 Open Burners, 24" Raised Griddle
90,000
595
One hour manual timer included on 37" and 49" models only.



Imperial Residential Ranges by DvorsonsImperial 49" Home Range with One 26-1/2" Oven
Model
Top Configuration
Gas Output
Ship Wt. lbs.
IDR-8
8 Open Burners
150,000
640
IDR-6-G12
6 Open Burners, 12" Griddle
135,000
650
IDR-4-G24
4 Open Burners, 24" Griddle
120,000
650
IDR-6-RG12
6 Open Burners, 12" Raised Griddle
135,000
670
IDR-4-RG24
4 Open Burners, 24" Raised Griddle
120,000
690
One hour manual timer included on 37" and 49" models only.


Imperial Residential Ranges by DvorsonsImperial 61" Home Range with Two 26-1/2" Ovens
Model
Top Configuration
Gas Output
Ship Wt. lbs.
IDR-10
10 Open Burners
210,000
920
IDR-8-G12
8 Open Burners, 12" Griddle
195,000
940
IDR-6-G24
6 Open Burners, 24" Griddle
180,000
980
IDR-6-RG24
6 Open Burners, 24" Raised Griddle
View Showroom Photos of model IDR-4-RG24 »
180,000
990


Imperial Residential Ranges by DvorsonsImperial 61" Home Range with One 26-1/2" Oven and One Cabinet Base
Model
Top Configuration
Gas Output
Ship Wt. lbs.
IDR-10-XB
10 Open Burners
180,000
880
IDR-8-G12-XB
8 Open Burners, 12" Griddle
165,000
900
IDR-6-G24-XB
6 Open Burners, 24" Griddle
150,000
940
IDR-6-RG24-XB
6 Open Burners, 24" Raised Griddle
150,000
950

Options & Accessories for Imperial Home Ranges (Imperial Range Discontinued Home Model Series in 2016)

Imperial 37" Home Range Options
Stainless Steel Backguard, 22" High with Stainless Steel High Shelf
Stainless Steel Curb Base Kit
Imperial 49" Home Range Options
Stainles Steel Backguard, 22" High with Stainless Steel High Shelf
Stainless Steel Curb Base Kit
Imperial 61" Home Range Options
Stainless Steel Backguard, 22" High with Stainless Steel Shelf
Stainless Steel Curb Base Kit
All Imperial Home Ranges Optional Features
Stainless Steel Side Panel (priced per side)
10" Wok Ring
Stainless Steel Griddle Cover/Work Top Surface 12"
Stainless Steel Griddle Cover/Work Top Surface 24"
Lift Off Griddle Plate 12"
Lift Off Griddle Plate 24"
Extra Chrome Oven Rack
Grooved Griddle Plate (specify right or left) -priced per foot
Chrome Griddle Top (add "CG" to model #) -priced per lineal foot
Hardwood Cutting Board -priced per lineal foot
Swivel Casters, set of 4 with front brakes
Double Pane window for Oven Doors -priced per door

Click here for Imperial Home Range Installation Dimensions page »


Specifications for Imperial Range
Imperial Range Equipment is Made in USA (Southern California)
